Storage
|
Total installed storage capacity
|
0 TB
|
|
Number of storage drives installed
|
0
|
|
Number of storage drives supported
|
4
|
|
Installed storage drive type
|
|
|
Supported storage drive types
|
HDD & SSD
|
|
Storage drive capacity
|
0 GB
|
|
Supported storage drive interfaces
|
Serial ATA, Serial ATA II, Serial ATA III
|
|
Storage drive sizes supported
|
2.5,3.5,M.2
|
|
Maximum supported storage capacity
|
40 TB
|
|
Number of M.2 (M & B) slots
|
2
|
|
RAID levels
|
0, 1, 5, 6, 10, JBOD
|
|
Supported file systems
|
BTRFS, Fat, HFS+, NTFS, ext3, ext4
|
Processor
|
Processor manufacturer
|
Intel
|
|
Processor family
|
Intel® Celeron®
|
|
Processor frequency
|
1.5 GHz
|
|
Processor boost frequency
|
2.3 GHz
|
|
CPU configuration (max)
|
1
|
|
ECC supported by processor
|
|
|
PCI Express configurations
|
1x2+2x1, 4x1
|
|
PCI Express slots version
|
2.0
|
|
Processor cache type
|
Smart Cache
|
|
Processor codename
|
Apollo Lake
|
|
Processor lithography
|
14 nm
|
|
Processor operating modes
|
64-bit
|
|
Processor package size
|
24 x 31 mm
|
|
Processor socket
|
BGA 1296
|
|
Thermal Design Power (TDP)
|
10 W
|
|
On-board graphics card model
|
Intel® HD Graphics 500
|
|
Maximum internal memory supported by processor
|
8 GB
|
Memory
|
Internal memory type
|
DDR3L
|
|
Maximum RAM supported
|
8 GB
|
Network
|
Ethernet LAN data rates
|
10,100,1000 Mbit/s
|
Ports & interfaces
|
Ethernet LAN (RJ-45) ports
|
2
|
|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
|
2
|
Graphics
|
On-board graphics card base frequency
|
250 MHz
|
|
On-board graphics card burst frequency
|
750 MHz
|
|
On-board graphics card dynamic frequency (max)
|
750 MHz
|
|
Maximum on-board graphics card memory
|
8 GB
|
|
Number of displays supported (on-board graphics)
|
3
|
Design
|
LED indicators
|
HDD, Power, Status
|
|
Cable lock slot type
|
Kensington
|
Performance
|
Device class
|
Small & Medium Business
|
|
Backup features
|
iSCSI LUN
|
|
Number of users
|
2048 user(s)
|
|
Access Control List (ACL)
|
|
Software
|
Operating system installed
|
DiskStation Manager
|
|
Operating system version
|
6.2.3
|
|
Windows operating systems supported
|
Windows 10, Windows 7
|
|
Mac operating systems supported
|
Mac OS X 10.11 El Capitan
|
Power
|
Power supply location
|
External
|
|
Power supply unit (PSU) capacity
|
100 W
|
|
Power consumption (typical)
|
28.8 W
|
|
Power consumption (sleep)
|
12.6 W
|
|
AC input voltage
|
100 - 240 V
|
|
AC input frequency
|
50 - 60 Hz
|
Weight & dimensions
Processor special features
|
Embedded options available
|
|
|
Enhanced Intel SpeedStep Technology
|
|
|
Intel Clear Video Technology
|
|
|
Intel Enhanced Halt State
|
|
|
Intel Identity Protection Technology version
|
1.00
|
|
Intel Rapid Storage Technology
|
|
|
Intel Secure Boot Technology version
|
1.00
|
|
Intel Secure Key Technology version
|
1.00
|
|
Intel Small Business Advantage (SBA) version
|
0.00
|
|
Intel Smart Connect Technology
|
|
|
Intel Smart Connect Technology version
|
0.00
|
|
Intel Smart Response Technology version
|
0.00
|
|
Intel Stable Image Platform Program (SIPP)
|
|
|
Intel Stable Image Platform Program (SIPP) version
|
0.00
|
|
Intel Trusted Execution Technology
|
|
|
Intel Virtualization Technology (VT-x)
|
|
|
Intel Virtualization Technology for Directed I/O (VT-d)
|
|
|
Intel VT-x with Extended Page Tables (EPT)
|
|
|
Intel® AES New Instructions (Intel® AES-NI)
|
|
|
Intel® Anti-Theft Technology (Intel® AT)
|
|
|
Intel® Clear Video HD Technology (Intel® CVT HD)
|
|
|
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)
|
|
|
Intel® High Definition Audio (Intel® HD Audio)
|
|
|
Intel® Hyper Threading Technology (Intel® HT Technology)
|
|
|
Intel® Identity Protection Technology (Intel® IPT)
|
|
|
Intel® InTru™ 3D Technology
|
|
|
Intel® Quick Sync Video Technology
|
|
|
Intel® Small Business Advantage (Intel® SBA)
|
|
|
Intel® Smart Response Technology
|
|
|
Intel® Turbo Boost Technology
|
|
|
Intel® Wireless Display (Intel® WiDi)
|
|
|
Maximum number of PCI Express lanes
|
6
|
|
Number of execution units
|
12
|
|
Thermal Monitoring Technologies
|
|
|
Home Networking (by Intel)
|
|
|
Memory channels supported by processor
|
Dual
|
|
Memory types supported by processor
|
DDR3L, LPDDR3-SDRAM, LPDDR4-SDRAM
|
Packaging content
|
Cables included
|
AC, LAN (RJ-45)
|
Operational conditions
|
Operating temperature (T-T)
|
5 - 40 °C
|
|
Operating relative humidity (H-H)
|
5 - 95%
|
|
Storage temperature (T-T)
|
-20 - 60 °C
|
|
Operating altitude
|
0 - 5000 m
|
Logistics data
|
Harmonized System (HS) code
|
84714100
|
Other features
|
Certification
|
FCC Class B
CE Class B
BSMI Class B
|
|
