Shuttle XPС slim DS10U5 PC/workstation barebone 1.3L sized PC Black i5-8265U Intel SoC BGA 1528 1.6 GHz

DS10U5

(Shuttle XPC slim DS10U5 Desktop Computer - Intel Core i5 8th Gen i5-8265U 1.60 GHz DDR4 SDRAM - Slim PC)

Product Image
Image accuracy is not guaranteed. Please do not rely on the image for your purchase.

View Product Demo

£527.00 | £632.40 inc.VAT

Overseas Customers with EU-VAT number do not pay VAT. - Verify it here

  • Quick Code: B43700448
  • MPN: DS10U5
  • Manufacturer: Shuttle
  • EAN code:
icon_cash_tag_large.jpg (130×105) Get £3.79 Cash Back if paying by Debit Card or Bank Transfer!

Learn more

Request More Info
Notify me when price drops
NOTE: The information below is provided for your convenience only and we cannot guarantee its accuracy. If necessary, please verify with us before purchasing.

Processor
Built-in processor
Processor manufacturer Intel
Processor family Intel® Core™ i5
Processor generation 8th gen Intel® Core™ i5
Processor model i5-8265U
Processor cores 4
Processor threads 8
Processor boost frequency 3.9 GHz
Processor frequency 1.6 GHz
Processor lithography 14 nm
Thermal Design Power (TDP) 15 W
Processor codename Whiskey Lake
CPU configuration (max) 1
Memory
Memory slots type SO-DIMM
Number of memory slots 2
Maximum internal memory 32 GB
Supported memory clock speeds 2133,2400 MHz
Supported memory types DDR4-SDRAM
Memory channels Dual-channel
Memory voltage 1.2 V
Non-ECC
Storage
Supported storage drive types HDD & SSD
Storage drive sizes supported 2.5"
Storage drive interface Serial ATA
Card reader integrated
Compatible memory cards SD, SDHC, SDXC
Graphics
On-board graphics card
Graphics card family Intel
On-board graphics card model Intel® UHD Graphics 620
Network
Ethernet LAN
Wi-Fi
Wi-Fi standards 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
LAN controller Intel® I211, Intel I219LM
Bluetooth
Bluetooth version 4.0
Ports & interfaces
USB 2.0 ports quantity 4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity 4
HDMI ports quantity 1
HDMI version 2.0a
VGA (D-Sub) ports quantity 1
DisplayPorts quantity 1
DisplayPort version 1.2
Microphone in
Headphone outputs 1
Ethernet LAN (RJ-45) ports 2
Serial ports quantity 1
DC-in jack
Expansion slots
PCI Express slots version 3.0
PCI Express configurations 1x4, 2x2
Design
Chassis type 1.3L sized PC
Product colour Black
Cooling type Passive
LED indicators HDD, Power
Cable lock slot
Cable lock slot type Kensington
VESA mounting
Safety ETL, CB, BSMI
Performance
Motherboard chipset Intel SoC
Processor socket BGA 1528
Number of processors supported 1
BIOS type UEFI AMI
Audio output channels 2.0 channels
Audio chip Realtek ALC662
Processor special features
Embedded options available
Intel® AES New Instructions (Intel® AES-NI)
Intel® Quick Sync Video Technology
Intel® Clear Video HD Technology (Intel® CVT HD)
Intel® Turbo Boost Technology 2.0
Intel® Hyper Threading Technology (Intel® HT Technology)
Intel Virtualization Technology for Directed I/O (VT-d)
Intel VT-x with Extended Page Tables (EPT)
Intel 64
Intel® My WiFi Technology (Intel® MWT)
Idle States
Enhanced Intel SpeedStep Technology
Thermal Monitoring Technologies
Intel Flex Memory Access
Intel® Identity Protection Technology (Intel® IPT)
Intel Trusted Execution Technology
Execute Disable Bit
Intel TSX-NI
Intel® Secure Key
Intel® Smart Response Technology
Intel Stable Image Platform Program (SIPP)
Intel® OS Guard
Intel Clear Video Technology
Intel Virtualization Technology (VT-x)
Sustainability
Sustainability certificates ENERGY STAR
Software
Windows operating systems supported Windows 10
Linux operating systems supported
Operating system installed
Certificates
Certification FCC, CE, BSMI, C-Tick, ErP
Power
Power supply type External AC adapter
Power supply 65 W
Number of power supply units 1
AC input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
AC adapter output voltage 19 V
AC adapter output current 3.42 A
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Operating relative humidity (H-H) 10 - 90%
Weight & dimensions
Width 165 mm
Depth 200 mm
Height 39.5 mm
Weight 1.5 kg
Package weight 2.2 kg
Packaging content
Power cord included
AC adapter included
Quick start guide
Drivers included
Other features
Processor ARK ID 149088
