Display
Display diagonal
|
60.5 cm (23.8")
|
Display resolution
|
1920 x 1080 pixels
|
Display brightness (typical)
|
250 cd/m²
|
Supported graphics resolutions
|
1920 x 1080 (HD 1080)
|
Supported video modes
|
480p, 576p, 720p, 1080i, 1080p
|
Contrast ratio (typical)
|
3000:1
|
Maximum refresh rate
|
75 Hz
|
Viewing angle, horizontal
|
178°
|
Viewing angle, vertical
|
178°
|
Display number of colours
|
16.7 million colours
|
Response time (fast)
|
8 ms
|
Pixel pitch
|
0.2745 x 0.2745 mm
|
Horizontal scan range
|
30 - 83 kHz
|
Vertical scan range
|
48 - 75 Hz
|
Viewable size, horizontal
|
52.7 cm
|
Viewable size, vertical
|
29.6 cm
|
Viewable size diagonal
|
60.5 cm
|
Display diagonal (metric)
|
60.45 cm
|
High Dynamic Range (HDR) supported
|
|
NTSC coverage (typical)
|
72%
|
Performance
Low Blue Light technology
|
|
Multimedia
Design
Market positioning
|
Business
|
Ports & interfaces
VGA (D-Sub) ports quantity
|
1
|
Network
Ergonomics
Panel mounting interface
|
100 x 100 mm
|
Tilt angle range
|
-5 - 21°
|
Power
Energy efficiency class (SDR)
|
E
|
Energy efficiency class (HDR)
|
Not available
|
Energy consumption (SDR) per 1000 hours
|
16 kWh
|
Power consumption (typical)
|
15.7 W
|
Power consumption (standby)
|
0.3 W
|
Power consumption (max)
|
24 W
|
Power consumption (off)
|
0.3 W
|
Power consumption (PowerSave)
|
15.9 W
|
AC input voltage
|
100 - 240 V
|
AC input frequency
|
50 - 60 Hz
|
Power supply type
|
Internal
|
Energy efficiency scale
|
A to G
|
European Product Registry for Energy Labelling (EPREL) code
|
494247
|
Operational conditions
Operating temperature (T-T)
|
0 - 40 °C
|
Storage temperature (T-T)
|
-20 - 60 °C
|
Operating relative humidity (H-H)
|
20 - 90%
|
Storage relative humidity (H-H)
|
5 - 90%
|
Operating altitude
|
0 - 5000 m
|
Non-operating altitude
|
0 - 12192 m
|
Weight & dimensions
Width (with stand)
|
552.6 mm
|
Depth (with stand)
|
178.8 mm
|
Height (with stand)
|
420.2 mm
|
Weight (with stand)
|
3.77 kg
|
Width (without stand)
|
552.6 mm
|
Depth (without stand)
|
49.7 mm
|
Height (without stand)
|
331.6 mm
|
Weight (without stand)
|
3.18 kg
|
Bezel width (side)
|
1.28 cm
|
Bezel width (top)
|
1.28 cm
|
Bezel width (bottom)
|
1.69 cm
|
Packaging data
Packaging content
Cables included
|
AC, HDMI, VGA
|
Sustainability
Carbon footprint
Total carbon footprint (kg of CO2e)
|
501
|
Total carbon emissions, standard deviation (kg of CO2e)
|
129
|
Carbon emissions, manufacturing (kg of CO2e)
|
326.45
|
Carbon emissions, logistics (kg of CO2e)
|
24.1
|
Carbon emissions, energy usage (kg of CO2e)
|
148
|
Carbon emissions, end-of-life (kg of CO2e)
|
2.78
|
Total carbon emissions, w/o use phase (kg of CO2e)
|
353
|
Other features
Heavy metals free
|
Hg (mercury)
|
Ethernet LAN (RJ-45) ports
|
0
|
Logistics data
Harmonized System (HS) code
|
85285210
|
|
