Perle PSM-ME-RS232/RS232-P serial converter/repeater/isolator RS-232 Green
MPN: 27444618
Quick Code: B50942503
(PSM-ME-RS232/RS232-P - ISOLATORRS232 ISOLATION UP TO 2)
Note: Image accuracy is not guaranteed. Please do not rely solely on the image for your purchase.
$516.92
$620.30 inc. VAT
All products on this website are available duty-free in the EU
Overseas Customers with EU-VAT number do not pay VAT. - Verify it here
Overseas Customers with EU-VAT number do not pay VAT. - Verify it here
Quick Code:
B50942503
MPN:
27444618
Manufacturer:
Perle
EAN Code:
0679202033170
💰 Get $3.72 Cash Back if paying by Debit Card or Bank Transfer!
NOTE: The information below is provided for your convenience only and we cannot guarantee its accuracy. If necessary, please verify with us before purchasing.
Perle PSM-ME-RS232/RS232-P serial converter/repeater/isolator RS-232 GreenRS232/RS232, 15m, 115.2 Kbit/s, IP20, 24VAC/VDC, 100 mA
PSM-ME-RS232/RS232-P Serial IsolatorInterface converter for the electrical isolation of RS-232 interfaces
3-way EMI, RFI and Transient Surge Immunity
The RS-232 interface is an asymmetric voltage interface with common signal ground for all signals. In addition to its very low signal power, a characteristic feature of the interface is that the signal ground is connected to the grounded chassis housing. This results in very little immunity to interference and a maximum range of 15 meters. Using the PSM-ME-RS232/RS232-P Serial Isolator, considerably higher immunity to interference in industrial applications can be achieved. By isolating the TX/RX data channels and the RTS/CTS control lines the PSM-ME-RS232 Serial Isolator effectively protects your RS232 devices from transient surges, lightning strikes, ground loops and noise issues. With their high-grade 3-way isolation between both interface sides the PSM-ME-RS232 provides a floating and interference resistant RS-232 interface for the supply and ground potential. Expensive termination devices are also protected against damage by this decoupling. Any additional potential EMI can be removed from the transmission path by using additional PSM-ME-RS232 Serial Isolators on both device interfaces. The PSM-ME-RS232 Serial Isolators can be wall mount AC powered or snapped onto standard DIN rails supplied with 24V DC or AC. In the case of variable cable lengths, the RS-232 connection on the field side can be established conveniently using plug-in screw terminal blocks
