Brainboxes ED-588 Ethernet to 8 Digital Inputs and 8 Digital Outputs + Serial Gateway
MPN: ED-588
Quick Code: B1702572
(Brainboxes Ethernet to Digital ED-588)
Note: Image accuracy is not guaranteed. Please do not rely solely on the image for your purchase.
$255.01
$306.01 inc. VAT
All products on this website are available duty-free in the EU
Overseas Customers with EU-VAT number do not pay VAT. - Verify it here
Overseas Customers with EU-VAT number do not pay VAT. - Verify it here
Quick Code:
B1702572
MPN:
ED-588
Manufacturer:
Brainboxes
EAN Code:
💰 Get $1.84 Cash Back if paying by Debit Card or Bank Transfer!
NOTE: The information below is provided for your convenience only and we cannot guarantee its accuracy. If necessary, please verify with us before purchasing.
Brainboxes ED-588 Ethernet to 8 Digital Inputs and 8 Digital Outputs + Serial GatewayEthernet to 8 Digital Inputs, 8 Digital Outputs, RS485 Gateway
Ethernet to DIO device: 8 non-isolated digital input channels and 8 digital output channels. Powerful ARM 80 MHz, 32 Bit CPU. Offers robust and intelligent 'control side' devices that provide the interface to systems on the 24V factory floor environment, commonly referred to as 'process side'.The device can be controlled over TCP/IP using the Modbus TCP protocol or simple ASCII commands. Additionally Brainboxes supply a suite of APIs and sample code to communicate with the device using Microsoft .NET framework Visual Basic, C#, C++, Java, Javascript, PHP and more. The device can be configured and secured from a web browser. The device can be installed as a COM Port on a Windows PC to give complete backwards compatibility essential for legacy applications.
The ED product range is designed for harsh environments. The digital output port lines are implemented as protected output circuits, providing current overload and short circuit protection, voltage surge, overload and open circuit protection and over temperature protection to allow the widest possible usage and range of devices.
The outputs are good for driving hot and cold resistive loads, capacitive loads and inductive loads and are especially suited for loads with high inrush currents such as cold bulbs/lamps and motors. Typical applications are control and switching of AC and DC motors, Fans, relay drivers, pumps, Voltage Regulators and Battery Chargers, LEDs and Bulbs, Air Conditioning, Heaters and Solenoids..
